We can offer a full build and PDI service, which will increase shipping costs and will be done on a case by case system. If you want this option you should choose the local pickup option and you will be invoiced for the shipping later.
Key Machine Features –
- Push-button electric start
- Wide axles & low centre of gravity for added stability
- Front & rear brakes
- Easy access choke lever for cold start days
- Chunky off-road tyres
- 12 Month main parts warranty & full spare parts back up
General Specifications
| WEIGHT | 73KG |
|---|---|
| CLEARANCE | 80MM |
| DIMENSIONS | LENGTH = 1080MM / WIDTH = 680MM / HEIGHT = 800MM |
| SEATS | SINGLE CAPACITY CUSHIONED SEAT (SEAT HEIGHT = 580MM) |
| AXLE | WIDE AXLE FOR STABILITY |
| FRAME | QUALITY CHROMOLY FINISH |
| TYRES | FRONT / REAR = 145 X 70 – 6 OFF ROAD PATTERN |
| BRAKES | FRONT DRUM BRAKES / REAR HYDRAULIC CALIPER + REAR BRAKE DISC |
| WHEELS | BLACK COATED STEEL RIMS – 6” FRONT & 6” REAR |
| SUSPENSION | INDEPENDENT WISHBONES FRONT / SWING ARM – SOLID AXLE REAR |
| SHOCKS | FRONT INDEPENDENT SHOCKS / REAR MONO SHOCK |
Engine & Transmission Specifications
| FINAL DRIVE | SOLID REAR AXLE |
|---|---|
| DRIVE | CHAIN DRIVE – WITH CHAIN GUARD |
| TRANSMISSION | FULLY AUTOMATIC – TORQUE CONVERTOR – NO GEARS |
| OIL | 10W/40 (NO FUEL / OIL MIXING IS REQUIRED) |
| FUEL / CAPACITY | STANDARD 4 STROKE PETROL / 2.3L FUEL TANK CAPACITY |
| COOLING | AIR COOLED |
| START | PUSH BUTTON - ELECTRIC KEY START (REMOVABLE FOR SAFETY) |
| TOP SPEED | 8 - 25MPH+ (FULLY RESTRICTABLE) |
| CHOKE | INCLUDED EASY ACCESS LEVER (FOR COLD START DAYS) |
| MODEL | RENEGADE 70CC |
| ENGINE | 70CC – SINGLE CYLINDER – PZ19 CARBURETOR |
